产品编号Product number

BD25C

转向类型Steering type

电子electronic

载荷Load

kg

2500

载荷中心距Load center distance

Mm

600

承载长度Carrying length

mm

980

轴距Wheelbase

Mm

1595

自重Self weight

Kg

510

满载驱动端Full load driver

Kg

860/1650

空载驱动端No-load drive

kg

405/105

轮胎类型Tire type

聚氨酯Polyurethane

驱动轮尺寸Drive wheel size

mm

Φ230×75

承载尺寸Carrying size

mm

2×Φ85×70

平衡轮尺寸Balance wheel size

mm

Φ102×63.5

驱动轮Drive wheel

mm

1×＋1/4

前轮距Front track

mm

442

后轮距Rear track

mm

370/430/515

起升高度Lifting height

mm

120

工作高度Working height

mm

1180

货叉下降高度

mm

85

整车长度Fork drop height

mm

1930

货叉垂直长度Fork vertical length

mm

780

整车宽度Vehicle width

mm

730

货叉尺寸Fork size

mm

55×170×1150

货叉外宽Outer fork width

mm

540/600/685

最小离地间隙Minimum ground clearance

mm

25

转弯半径Turning radius

mm

1790

行走速度，满载/空载Walking speed, full load / no load

Km/h

5.5/6

起升速度，满载/空载Lifting speed, full load / no load

m/s

0.23/0.030

下降速度，满载/空载Falling speed, full load / no load

m/s

0.032/0.029

最大爬坡度，满载/空载Maximum grade, full load / no load

%

8/16

制动类型Brake type

电磁式Electromagnetic

驱动电机Drive motor

kw

1.5

起升电机Lifting motor

Kw

0.84
