产品编号Model Number |
DW10G30 |
DW15G30 |
DW20G30 |
|
额定载荷/Rated Capacity |
kg |
1000 |
1500 |
2000 |
载荷中心/Load Center |
mm |
400 |
||
货叉最大高度/Max.Fork Height |
mm |
3000 |
||
机器最大高度 /Max.Machine Height |
mm |
3560 |
||
操纵手柄高度/Handle Height |
mm |
1450~1460 |
||
货叉尺寸/Fork Size |
mm |
1150×160 |
||
货叉外宽/Fork Width |
mm |
570(680) |
||
最小转弯半径 /Min.Turning Radius |
mm |
1620 |
||
前后轮轴距/Wheel Base |
mm |
1340 |
||
前轮基距/Front-Wheel Distance |
mm |
339 |
||
空载最大行驶速度/Max.Speed Without Load |
km/h |
4.5~6 |
||
满载最大行驶速度 /Max.Speed With Load |
km/h |
4~5 |
||
最大爬坡能力/Max.Climbing Capacity |
% |
8~10 |
||
驱动电机/Driving Motor |
v/kw |
24/1.2 |
||
举升电机/Lifting Motor |
v/kw |
24/2~3 |
||
免维护电池/Anerold battery |
v/Ah |
12×2/210 |
||
充电器/Charger |
V/A |
24/20-30 |
||
整机长度/Overall Length |
mm |
2000 |
||
整机宽度/Overall Width |
mm |
860 |
||
整机高度Overall Height |
mm |
2080 |
||
整机重量/Overall Net Weight |
kg |
680 |
710 |
825 |
