型号规格Model Number

BD20D

额定载荷Rated Capacity  (Q)

kg

2000

载荷中心Load Center (C)

mm

600

货叉最大高度Max Fork Heigh (H4)

mm

250

货叉最低高度Min Fork Height (H3)

mm

85

手柄高度Handle Height (H1)

mm

1400

车体高度Frame Height  (H2)

mm

890

货叉尺寸Fork Size (1xn)

mm

1150x160

贷叉外宽Fork Width (E)

mm

570

最小转弯半径Min. Turning Radius (Wa)

mm

1620

轴距Wheel Base (Y)

mm

1350

前轮距Front-Wheel Distance (X)

mm

385

空载最大行驶速度Max. speed without load

km/h

4.5~6

满载最大行驶速度Max.speed with loa

km/h

4~5

最大爬坡能力Max.travel Grade

%

8~10

驱动电机Driving Motor

v/kw

24/1.2

起升电机Lifting Motor

v/kw

24/2.2

蓄电池Battery

v/Ah

12x2/210

充电器Charger

v/A

24/20

整机长度 Overall Length (A)

mm

2000

整机宽度Overall Width (B)

mm

820

整机高度Overall Height (C)

mm

1400

整机重量Net Weight

kg

650
