产品编号/ Model Number

AW7595X

AW0911X

平台最大高度Max.Platform Height

mm

7500

9000

最大工作高度Max.Platform Work

mm

9500

11000

平台额定载荷Lift Rated Capacity

kg

200

150

工作平台尺寸Platform Size

mm

1000×700

最小离地间隙Ground Clearance

mm

50

轴距Wheel Base

mm

1280

最大爬坡能力Max. Climbing Capacity

%

25%

工作最大允许角度Maximum working allowable angle

3°

驱动轮Driving Wheel

φ250×80mm

前轮Front Wheel

8in

驱动电机Driving Motor

v/kw

2×24VDC/0.5kw

起升电机Lifting Motor

v/kw

24VDC/2kw

蓄电池Battery

v/Ah

2×12V/120Ah

充电器Charger

v/A

24V/12A

整机长度Overall Length

mm

1500

整机宽度Overall Width

mm

1000

整机高度Overall Height

mm

1990

整机重量Overall Net Weight

kg

1270

1350
