产品编号/ Model Number

AW0608S

AW7595S

平台最大高度Max.Platform Height

mm

6000

7500

最大工作高度Max.Platform Work

mm

8000

9500

平台额定载荷Lift Rated Capacity

kg

150

125

工作平台尺寸Platform Size

mm

780×700

最小离地间隙Minimum ground clearance

mm

50

轴距Wheel Base

mm

1070

最大爬坡能力Max. Climbing Capacity

%

25

工作最大允许角度Maximum working allowable angle

1.5°

驱动轮Driving Wheel

φ305x100mm

前轮 Front Wheel

8in

驱动电机Driving Motor

v/kw

2×24VDC/0.4kw

起升电机Lifting Motor

v/kw

24VDC/2kw

蓄电池Battery

v/Ah

2×12V/120Ah

充电器Charger

v/A

24V/12A

整机长度Overall Length

mm

1430

整机宽度Overall Width

mm

760

整机高度Overall Height

mm

1980

整机重量Overall Net Weight

kg

1010

1052
