型号规格 Model Number

GD0608F

GD0810F

GD1012F

GD1214F

最大工作高度/Maximum working height

mm

8000

10000

12000

14000

最大平台高度/Maximum platform height

mm

6000

8000

10000

12000

额定载荷/Whole weight

kg

300

300

300

320

工作平台尺寸/Platform Size

mm

2270×1150

2270×1150

2270×1150

2270×1150

工作延伸尺寸/Platform extend size

mm

900

900

900

900

最小离地间隙（收拢状态）Minimumground clearance(folding)

mm

110

110

110

110

最小离地间隙（起升状态）/Minimumground clearance(rising)

mm

20

20

20

20

轴距/Wheelbase

mm

1850

1850

1850

1850

最小转弯半径（内轮）/ Minimum turn radius(inner wheel)

mm

0

0

0

0

最小转弯半径（外轮）/Minimum turn radius(outer wheel)

mm

2100

2100

2100

2100

电机功率/Power source

v/kw

24/3

24/3

24/3

24/3

机器行使速度（收拢状态/）Running speed(folding)

km/h

3.5

3.5

3.5

3.5

机器行使速度（起升状态）/Running speed(rising)

km/h

0.8

0.8

0.8

0.8

上升/下降速度/Rising/falling speed

sec

40/50

40/50

70/80

70/80

蓄电池/Battery

V/Ah

4×6/210

4×6/210

4×6/210

4×6/210

充电器/Charger

V/A

24/25

24/25

24/25

24/25

最大爬坡能力/Maximum climbing ability

%

20

20

20

20

工作最大允许角度/Maximum working allowable angle

/

2-3°

2-3°

2-3°

2-3°

控制方式/Way of control

/

电液比例控制Electro-hydraulic proportion control

驱动/Driver

/

双前轮Double front-wheel

液压制动/Hydraulic drive

/

双后轮Double rear-wheel

轮台尺寸（实心无痕）/Wheel size(stuffed&no mark)

/

Φ381×127

Φ381×127

Φ381×127

Φ381×127

收起时最大高度（栏杆立起）Folding maximum height(guardrail unfolding)

mm

2150

2275

2400

2525

收起时最大高度（栏杆拆除）Folding maximum height(guardrail removed)

mm

1190

1315

1440

1565

整机长度Overall Length

mm

2400

2400

2400

2400

整机宽度Overall Width

mm

1150

1150

1150

1150

整体重量Lifting capacity

kg

1900

2080

2490

2760
